FLIR SR-Series Technical Specifications

Fixed-site Thermal Security Cameras


Camera Platform Type

 Fixed Fixed Fixed

Thermal Camera Specs
Array Format (NTSC) 160 x 120 320 × 240 640 × 480
Detector Type Long-Life, Uncooled
VO× Microbolometer		 Long-Life, Uncooled
VO× Microbolometer		 Long-Life, Uncooled
VO× Microbolometer
Effective Resolution 19,200 76,800 307,200
Pixel Pitch 25 μm 25 μm 17 μm
Field Of View 24° × 20° (F-124; 9 mm)
17° × 14° (F-117; 13 mm)
12° × 10° (F-112; 19 mm)		 48° × 39° (F-348; 9 mm)
34° × 28° (F-334; 13 mm)
24° × 19° (F-324; 19 mm)
13 °× 10° (F-313; 35 mm)
7° × 5° (F-307; 65 mm)
4.6° × 3.7° (F-304; 100 mm)		 45° × 37° (F-645; 13 mm)
25° × 20° (F-625; 25 mm)
18° × 14° (F-618; 35 mm)
12° × 10° (F-612; 50 mm)
10° × 8° (F-610; 65 mm)
6.2° × 5° (F-606; 100 mm)
Zoom 2× E-zoom 2× & 4× E-zoom 2× & 4× E-zoom
Spectral Range 7.5 μm to 13.5 μm 7.5 μm to 13.5 μm 7.5 μm to 13.5 μm
Focus Range Athermalized, focus-free Athermalized, focus-free Athermalized, focus-free
Frame Rate NTSC: 30 Hz; PAL 25 Hz NTSC: 30 Hz; PAL 25 Hz NTSC: 30 Hz; PAL 25 Hz

Outputs
Composite Video NTSC or PAL Standard Standard Standard

Control
Point To Point (stand alone) Standard Standard Standard
Serial RS-422/232 RS-422/232 RS-422/232

General
Weight ~46 lb (configuration dependent) ~46 lb (configuration dependent) ~46 lb (configuration dependent)
Dimensions (L,W,H) 13.7" × 18.4" × 12.8" 13.7" × 18.4" × 12.8" 13.7" × 18.4" × 12.8"
Power Requirements 21-30 VAC
21-30 VDC		 21-30 VAC
21-30 VDC		 21-30 VAC
21-30 VDC
Power Consumption 24 VAC: 15 VA (max w/o heaters);
51 VA (max w/heaters)
24 VDC: 10 W (max w/o heaters);
46 W (max w/heaters)		 24 VAC: 15 VA (max w/o heaters);
51 VA (max w/heaters)
24 VDC: 10 W (max w/o heaters);
46 W (max w/heaters)		 24 VAC: 15 VA (max w/o heaters);
51 VA (max w/heaters)
24 VDC: 10 W (max w/o heaters);
46 W (max w/heaters)





กล้องถ่ายภาพความร้อน Flir

SR-Series imagers are fixed-site thermal security cameras that come in ruggedized, all-weather enclosures that are compatible with a wide variety of third-party accessories, making them easy to integrate. SR-Series cameras define the new standard of performance with five models with full 640 × 480 thermal resolution that give you greater image detail, more extensive coverage, and better analytics performance than ever before.
