FLIR A310 Thailand Infrared Camera Specifications

Safety: the Infrared eye that never sleeps


The FLIR A310 camera offers an affordable and accurate temperature measurement solution for anyone who needs to solve problems that need built in "smartness" such as analysis, alarm functionality and autonomous communication using standard protocols. The FLIR A310 camera also has all the necessary features and functions to build distributed single- or multi-camera solutions utilizing standard Ethernet hardware and software protocols.


The FLIR A310 camera also has built in support to connect to industrial control equipment such as PLCs, and allows for sharing of analysis and alarm results and simple control using the Ethernet/IP and Modbus TCP field bus protocol.


Imaging and optical data
Field of view (FOV) 25° x 18.8°
Minimum focus distance 0.4m
Focal Length 18mm
Spatial resolution 1.36mrad
Lens identification Automation
F-number 1.3
Thermal sensitivity/ NETD <0.05°C @ + 30°C/ 50mK
Image frequency 30Hz
Focus Automatic or manual (built in motor)
Zoom 1-8x continuous, digital, interpolating zooming on images

Detector data
Detector type Focal Plane Array (FPA), uncooled microbolometer
Spectral range 7.5-13μm
IR resolution 320 x 240pixels
Detector pitch 25μm
Detector time constant Typical 12ms

Measurement
Object temperature range -20°C to + 120°C
0 to +350°C
Accuracy ±2°C or ±2% of reading

Measurement analysis
Spotmeter 10
Area 10 boxes with max./min./average/position
Isotherm 1 with above/ below/ interval
Measurement Option Measurement Mask Filter Schedule response: File sending (ftp), email (SMTP)
Difference temperature Delta temperature between measurement
functions or reference temperature
Atmosphere transmission Automatic, based on inputs for distance,
atmospheric temperature and relative humidity
Optics transmission
correction		 Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0
Reflected apparent
temperature correction		 Automatic, based on input of reflected temperature
External optics/
windows correction		 Automatic, based on input of optics/ window transmission and temperature
Measurement corrections Global object parameters

Alarm
Alarm functions 6 automatic alarms on any selected measurement function, Digital In, Camera temperature, timer
Digital Out, Log, store image, file sending (ftp)
Alarm output email (SMTP), notification

Set-up
Color palettes Color palettes (BW, BW inv, Iron, Rain)
Set-up commands Date/ time, Temperature°C

Storage of images
Image storage type Built-in memory for image storage
File format Standard JPEG, 16-bit measurement data included

Ethernet
Ethernet Control and image
Ethernet, type 100Mbps
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication TCP/IP socket-based FLIR proprietary
Ethernet, video streaming MPEG-4, ISO.IEC 14496-1 MPEG-4 ASP@L5
Ethernet, image streaming 16-bit 320 x 240 pixels @ 3 Hz
Ethernet, power Power over Ethernet, PoE Ieee 802.3af class 0
Ethernet, protocols TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour), uPnP

Digital input/output
Digital input, purpose Image tag (start/ stop/ general), Input ext. device (programmatically read)
Digital input 2 opto-isolated, 10-30 VDC
Digital ouput, purpose Output to ext. device
(programmatically set)
Digital ouput 2 opto-isolated, 10-30 VDC, max 100mA
Digital I/O, isolation voltage 500VRMS
Digital I/O, supply voltage 12/24 VDC, max 200 mA
Digital I/O, connector voltage 6-pole jackable screw terminal

Composite video
Video out Composite video output, PAL and NTSC compatible
Video, standard CVBS (ITU-R-BT.470 PAL/ SMPTE 170M NTSC)
Video, connector type Standard BNC connector

Power system
External power operation 12/24 VDC, 24W absolute max
External power, connector type 2-pole jackable screw terminal
Voltage Allowed range 10-30 VDC

Environmental data
Operating temperature range -15°C to +50°C
Storage temperature range -40°C to +70°C
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C
EMC - EN 61000-6-2:2001 (Immunity)
- EN 61000-6-3:2001 (Emission)
- FCC 47 CFR Part 15 Class B (Emission)
Encapsulation IP 40 (IEC 60529)
Bump 25g (IEC 60068-2-29)
Vibration 2g (IEC 60068-2-6)

Physical data
Weight 0.7kg
Camera size (L x W x H) 170 x 70 x 70mm
Tripod mounting UNC1/4"-20 (on three sides)
Base mounting 2 x M4 thread mounting holes
(on three sides)
Housing materia Aluminium
