Highest sensitivity and most advanced feature set available. Supplies a combination of infrared and visible spectrum images of superior quality and temperature measurement accuracy – plus voice annotation, and a host of other advanced features.

Main Features & Benefits

• The FLIR SC620 supply a combination of infrared and visible spectrum images of superior quality and temperature measurement accuracy – plus GPS (SC660 only), voice annotation and a host of other advanced features.

• The high-definition 640×480 infrared detector delivers exceptional sensitivity, resolution, and image quality for scientific and research applications. The Dynamic Detail Enhancement (DDE) feature further improves thermal image sharpness.

• The digital Firewire interface connects to the PC running ThermaCAM Researcher – powerful thermographic software for real-time image recording and analysis.

• Visible spectrum images generated by the built-in high resolution digital camera can be fused with the IR images creating a Picture-in-Picture (PiP) view in real time. The PiP function has full flexibility allowing users to adjust the PiP area size and position.

The 5.6" widescreen LCD and built-in viewfinder allow on-camera viewing of images. The high quality lenses including USM technology have fast autofocus functions, as well as full manual adjustment.

Imaging and optical data
Field of view (FOV) / Minimum focus distance	24° × 18° / 0.3 m
Spatial resolution (IFOV)	0.65 mrad
Thermal sensitivity / NETD	<40 mK @ +30°C
Image frequency	30 Hz (60/120 Hz with windowing)
Focus	Automatic or manual (electric or on the lens)
Zoom	1–2× continuous, digital zoom, including panning
Focal Plane Array (FPA) / Spectral range	Uncooled microbolometer / 7.5–13 μm
IR resolution	640 × 480 pixels
Image presentation
Display	Built-in widescreen, 5.6 in. LCD, 1024 × 600 pixels
Viewfinder	Built-in, tiltable LCD, 800 × 600 pixels
Automatic image adjustment	Continuous / manual; linear or histogram based
Manual image adjustment	Level /span / max / min
Image modes	IR-image, visual image, thermal fusion, picture in picture, thumbnail gallery
Thermal fusion	IR image shown above, below or within temp interval on visual image
Picture in Picture	Resizable and movable IR area on visual image
Reference image	Shown together with live IR image
Measurement
Temperature range	–40°C to +500°C
Accuracy	±2°C or ±2% of reading
Measurement analysis
Spotmeter	3
Area	3 boxes or circles with max. / min. / average
Automatic hot / cold detection	Max / Min temp. value and position shown within box, circle or on a line
Isotherm	2 with above / below / interval
Difference temperature	Delta temperature between measurement functions or reference temperature
Reference temperature	Manually set or captured from any measurement function
Emissivity correction	Variable from 0.01 to 1.0 or selected from editable materials list
Measurement corrections	Reflected temperature, optics transmission, atmospheric transmission and external optics
Humidity alarm	1 humidity alarm, including dew point alarm
Insulation alarm	insulation alarm
Set-up
Set-up commands	Configurable measurement tools menu; configure information to be shown in image; 2 Programmable buttons; user profiles; local adaptation of units, language, date and time formats
Storage of images
Image storage	Standard JPEG, including measurement data, on memory card
Image storage mode	IR / visual images; simultaneous storage of IR and visual images Visual image is automatically associated with corresponding IR image
Periodic image storage	Every 10 seconds up to 24 hours
Panorama	For creating panorama images in FLIR Reporter Building software
Image annotations
Voice	60 seconds stored with the image
Text	Predefined text or free text from PDA (via IrDA) stored with the image
Image marker	4 on IR or visual image
Video recording and streaming
Radiometric IR-video streaming	Real-time full dynamic to PC using FireWire 30 Hz or 60/120 Hz with windowing using FLIR ResearchIR
Non-radiometric IR-video streaming	MPEG-4 to PC using USB or WLAN (optional)
Digital camera
Built-in digital camera	3.2 Mpixel, auto focus, and video lamp
Laser pointer
Laser	Activated by dedicated button
Data communication interfaces
Interfaces	USB-mini, USB-A, IrDA, composite video, headset connection
Power system
Battery	Li Ion, 3 hours operating time
Charging system	In camera (AC adapter or 12 V from a vehicle) or 2-bay charger
Power management	Automatic shutdown and sleep mode (user selectable)
Environmental data
Operating temperature range	-15°C to +50°C
Storage temperature range	-40°C to +70°C
Humidity (operating and storage)	IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C
EMC	- EN 61000-6-2:2001 (Immunity) - EN 61000-6-3:2001 (Emission) - FCC 47 CFR Part 15 Class B (Emission)
Encapsulation	IP 54 (IEC 60529)
Bump	25g (IEC 60068-2-29)
Vibration	2g (IEC 60068-2-6)
Physical data
Camera weight, incl. lens and battery	1.8 kg
Camera size (L x W x H)	299 × 144 × 147 mm
Tripod mounting	UNC1/4"-20 (on three sides)
